In English
UBBL07
Модель:
UBBL07
Напряжение:
3.7 В
Макс. ток:
3.5 A
Вес:
0.16 кг
Емкость:
6.1 А*ч
Зарядное устройство:
+
| Specifications | |||||||||
| Volt Range: | 3 to 4.2 V | ||||||||
| Average Voltage: | 3.7 V | ||||||||
| Nominal Capacity: | 6.1 Ah @ C/5 Rate @ 23° C | ||||||||
| Max. Discharge: | 3.5A continuous | ||||||||
| Pulse Capacity: | Varies according to pulse characteristics, temperature, cell history, and the application. | ||||||||
| Energy: | 22.6 Wh | ||||||||
| Energy Density: | 141 Wh/kg, 270 Wh/I | ||||||||
| Weight: | 160 Grams | ||||||||
| Cycle Life: | > 300 cycles @ C/5 to 80% of initial capacity | ||||||||
| Memory: | No Memory Effect | ||||||||
| Operating Temp.: | -20° C to 60° C | ||||||||
| Storage Temp.: | -20° C to 60° C | ||||||||
| Self Discharge: | < 10 % per Month | ||||||||
| Exterior/Housing: | PVC Shrink Wrap | ||||||||
| Terminals/Connector: | Wire leads: 26 AWG: Red (+), Black (-). Molex connector 87439-0400. Mates with 87437 & 87438. | ||||||||
| Safety: | UL component Recognized. Material Safety Datasheet - MSDS051. |
||||||||
| Transportation: | Excepted from Regulations | ||||||||
| Protection Circuit Module: |
|
||||||||
| Charging: | Maximum charge rate at C/2 to 4.2 Volts in a temperature range of 0° to 45° C. Hold at 4.2 Volts until current declines to C/10. Refer also to Safety Guide UBI-5112. | ||||||||
